HP Z4 G6i Workstation

Configure Your HP Z4 G6i Workstation

  • Configure

    Processor

    The HP Z4 G6i supports one Intel Xeon 600 series (LGA4710) processor, up to 300 watt TDP, for the ultimate performance.

    Hyper-Threading support allows two threads to run simultaneously on each core - recognizing up to 96 total cores, 48 real and 48 virtual. Turbo Boost support automatically boosts the processor speed based on workload - so if an application is only using one of the cores it will automatically increase the speed of the core in use and turn off the unused cores.

    Memory

    The HP Z4 G6i has 8 DIMM Slots supporting up to 1TB of DDR5 6400MT/s ECC Memory. Intel Xeon 600 series processors have 8 memory channels.

    We stock new condition, reputable brand memory including SK Hynix, Micron, and Samsung.

    Storage | M.2 Onboard

    The HP Z4 G6i has four onboard PCIe Gen5 M.2 slots supporting NVMe SSDs.

    PCIe 5.0 NVMe SSDs have read/write speeds averaging 12,000MB/s.

    We stock new condition, highest performance, Samsung and Western Digital drives.

    Storage | M.2 Add

    Four additional M.2 NVMe PCIe Gen5 SSDs can be added to the HP Z4 G6i via:

    • One HP Z Turbo Quad Pro PCIe Gen5 x16 internal NVMe carrier; four drives per adapter
    • One HP Front-Accessible Hot-Swappable external flexbay; two drives per flexbay

    Contact us after placing your order if you have a preference for the drives to be installed internally or externally.

    Storage | SATA

    The HP Z4 G6i has one internal 3.5-inch SATA drive bay.

    SATA SSDs have read/write speeds averaging 500MB/s.
    SATA Hard Drives have read/write speeds averaging 250MB/s.

    We stock new condition, reputable brand, and latest model drives.
    Hard drives are Western Digital or Seagate. Solid-state drives are Samsung.

    Solid-State Drive

    Hard Drive

    Optical

    The HP Z4 G6i has one external storage slot supporting one 9.5mm slim SATA optical drive.

    Graphics

    The HP Z4 G6i has three PCIe Gen5 x16 slots supporting up to three dual-width, full-height graphics cards.

    We stock NVIDIA Quadro professional-series and NVIDIA GeForce consumer-series graphics cards. If your application requires an AMD Radeon PRO graphics card, contact us for a custom quote.

    Thunderbolt

    Optional Thunderbolt 5 connectivity for high-performance external peripherals.

    AJA | Blackmagic Design

    Optional AJA connectivity cards and Blackmagic Design capture cards for professional video production applications. Contact us if the model you require is not listed.

    Network

    The HP Z4 G6i has one onboard 1Gb RJ45 Ethernet port. Add additional network adapters if you have a 10Gb network or connect to multiple networks.

    1GbE Network

    10GbE Network

    Wireless

    Optional WiFi network connection with an external antenna for extended range.

    Operating System

    Choose the operating system that best meets your application requirements. Windows 11 Professional for Workstations is installed by default. We also offer the most popular Linux distributions. If you would like dual-boot or multiple partitions, contact us for a custom quote.

    Operating System

    Load Operating System

    Keyboard

    Choose your ideal keyboard.

    Mouse

    Choose your ideal mouse.

    3Dconnexion

    Optional 3Dconnexion mice for professional CAD applications.

    Rack Mount Kit

    Optional rack rail kit to rackmount your HP Z4 G6i.

    $75 shipping per unit · Free local pickup

    Lead time: 1 to 2 weeks
    See Policies & FAQ for details.

    $ 6,250
  • Manufacture Year(s)2026
    Form FactorMid tower
    Processor FamilyIntel Xeon 600 series Processor
    Single Socket LGA-4710
    Up to 48 cores, up to 4.9 GHz
    ChipsetIntel W890
    Memory8 DIMM Slots
    8 Memory Channels
    Up to 1TB DDR5 6400 MT/s Registered ECC Memory
    StorageUp to 7 total drives
    4 M.2 NVMe PCIe Gen 5 slots onboard
    1 M.2 NVMe PCIe Gen 5 front-accessible, hot-swappable flexbays (optional)
    1 3.5-inch internal SATA drive bays
    1 5.25-inch external SATA optical/peripheral bays
    Network1 Onboard 1Gb Ethernet LAN port (Intel 1GbE I219-LM, vPro)
    Optional: Intel AX210 802.11AC WiFi & Bluetooth 5
    Optional: HP Dual-Port 10GbE Network Adapter
    Expansion Slots3 PCIe Gen5 x16
    1 PCIe Gen5 x4
    1 PCIe Gen4 x4
    All PCIe slots are accessible through the rear bulkhead
    Supports 3 full-height, double-width GPUs
    Ports and ConnectorsFront
    4 USB 3.2 Gen 1 Type-A
    1 headphone/microphone combo
    SD card reader (optional)

    Rear
    5 USB 3.2 Gen 1 Type-A
    5 USB 3.2 Gen 1 Type-C
    1 RJ45 1Gb Ethernet
    Power775W, Platinum Rated (92% Efficient)
    1350W @110V or 1700W @200V, Platinum Rated (92% Efficient)
    Dimensions13.8 x 24.1 x 24.8 in
    35.1 x 61.2 x 62.9 cm
    WeightStarting at 30.4 lb or 13.8 kg;
    Exact weight depends on configuration
    Manufacturer Product Page https://www.hp.com/us-en/workstations/z4.html

  • Documentation

    DatasheetView | Download
    QuickspecsView | Download
    HP Z4/Z8 Fury G6i Rail Rack KitView | Download
    Product Architecture WhitepaperView | Download
