HP Z6 G5 A Workstation

Configure Your HP Z6 G5 A Workstation

  • Configure

    Processor

    The HP Z6 G5 A supports one AMD Ryzen Threadripper PRO 7000 WX-Series CPU processor up to 96-cores for the ultimate performance.

    Hyper-Threading support allows two threads to run simultaneously on each core - recognizing up to 192 total cores, 96 real and 96 virtual. Turbo Boost support automatically boosts the processor speed based on workload - so if an application is only using one of the cores it will automatically increase the speed of the core in use and turn off the unused cores.

    Memory

    The HP Z6 G5 A has 8 DIMM Slots supporting up to 1TB of DDR5 5200MT/s ECC Memory. AMD Ryzen Threadripper PRO 7000WX processors have 8 memory channels.

    We stock new condition, reputable brand memory including SK Hynix, Micron, and Samsung.

    Storage | M.2

    The HP Z6 G5 A has four onboard PCIe 4.0 M.2 slots supporting NVMe SSDs.

    PCIe 4.0 NVMe SSDs have read/write speeds averaging 6,000MB/s.

    We stock new condition, reputable brand, and latest model drives.
    512GB to 2TB drives are Samsung. 4TB and 8TB drives are Sabrent or Corsair.

    Storage | M.2 Add

    Additional M.2 NVMe PCIe 4.0 SSDs can be added to the HP Z6 G5 A via:

    • Internal HP Z Turbo Quad Pro PCIe Gen 4 x16 card, supporting four drives
    • External HP Front-Accessible Hot-Swappable flexbay, supporting four drives

    Contact us after placing your order if you have a preference for the drives to be installed internally or externally.

    Storage | SATA

    The HP Z6 G5 A has two 3.5-inch SATA drive bays. Arrange any combination of hard drives or solid-state drives.

    SATA SSDs have read/write speeds averaging 500MB/s.
    SATA Hard Drives have read/write speeds averaging 250MB/s.

    We stock new condition, reputable brand, and latest model drives.
    Hard drives are Western Digital or Seagate. Solid-state drives are Samsung.

    • Solid-State Drive

      Hard Drive

    • Solid-State Drive

      Hard Drive

    Optical

    The HP Z6 G5 A has one 9.5mm slim SATA optical bay.

    Graphics

    The HP Z6 G5 A has four PCIe 4.0 and 5.0 x16 slots supporting up to three dual-width, full-height graphics cards.

    We stock NVIDIA Quadro professional-series and NVIDIA GeForce consumer-series graphics cards. If your application requires an AMD Radeon PRO graphics card, contact us for a custom quote.

    AJA | Blackmagic Design

    Optional AJA connectivity cards and Blackmagic Design capture cards for professional video production applications. Contact us if the model you require is not listed.

    Network

    The HP Z6 G5 A has one onboard 1Gb RJ45 Ethernet port. Add additional network adapters if you have a 10Gb network at your location or connect to multiple networks.

    1GbE Network

    10GbE Network

    Wireless

    Optional WiFi network connection with an external antenna for extended range.

    Operating System

    Choose the operating system that best meets your application requirements. Windows 11 Professional for Workstations is installed by default. We also offer the most popular Linux distributions. If you would like dual-boot or multiple partitions, contact us for a custom quote.

    Operating System

    Load Operating System

    Keyboard

    Choose your ideal keyboard.

    Mouse

    Choose your ideal mouse.

    3Dconnexion

    Optional 3Dconnexion mice for professional CAD applications.

    Rack Mount Kit

    Optional rail kit if you plan to rackmount your workstation.

    $75 shipping per unit · Free local pickup

    Lead time: 1 to 2 weeks
    See Policies & FAQ for details.

    $ 3,750
  • Manufacture Year(s)2023
    Form FactorMid tower
    Processor FamilyAMD Ryzen Threadripper PRO 7000 WX-Series
    Single Socket sTR5
    ProcessorsAMD Ryzen Threadripper PRO 7945WX | 12 cores, 4.7GHz base clock
    AMD Ryzen Threadripper PRO 7955WX | 16 cores, 4.5GHz base clock
    AMD Ryzen Threadripper PRO 7965WX | 24 cores, 4.2GHz base clock
    AMD Ryzen Threadripper PRO 7975WX | 32 cores, 4.0GHz base clock
    AMD Ryzen Threadripper PRO 7985WX | 64 cores, 3.2GHz base clock
    AMD Ryzen Threadripper PRO 7995WX | 96 cores, 2.5GHz base clock
    Up to 96 cores, up to 5.3GHz
    ChipsetIntel Alder Lake S PCH W790
    Memory8 DIMM Slots
    8 Memory Channels
    Up to 1TB DDR5 5200MT/s Registered ECC Memory
    StorageUp to 12 total drives
    4 M.2 NVMe SSD connections, onboard, tool-less
    4 M.2 NVMe SSD connections, front-accessible, hot-swappable
    4 M.2 NVMe SSD connections, Z Turbo Quad Pro PCIe card
    Network1 Onboard 10Gb Ethernet LAN port (Aquantia 10GbE AQC113C-B1-C)
    1 Onboard 1Gb Ethernet LAN port (Intel 1GbE I219)
    Optional: Intel AX210 802.11AC WiFi & Bluetooth 5
    Expansion Slots1 PCIe Gen 5 x16 slots
    2 PCIe Gen 4 x16 slots
    1 PCIe Gen 3 x16 slot
    2 PCIe Gen 4 x4 slots
    Supports 3 full-height, double-width GPUs
    Ports and ConnectorsFront
    4 USB 3.2 Gen 1 Type-A
    1 headphone/microphone combo
    SD card reader (optional)

    Rear
    6 USB 3.2 Gen 1 Type-A
    1 RJ45 1Gb Ethernet
    1 audio-in/out
    Power1125 watt 80+ gold internal power supply, 90% efficiency at 50% load (default)
    1450 watt 80+ gold internal power supply, 90% efficiency at 50% load
    Appropriate power supply is installed based on configuration.
    DimensionsHeight: 17.5" (445mm)
    Width: 6.7" (169mm)
    Depth: 18.3" (465mm)
    WeightTypical Configuration: 31lbs / 14kg
    Manufacturer Product Page https://www.hp.com/us-en/workstations/z6-a.html

  • Documentation

    Data SheetView | Download
    QuickspecsView | Download
