Keyshot

Keyshot

KeyShot is everything you need to create fast, accurate and amazing visuals. Featuring a real-time workflow to see your renderings and animations take shape instantly, KeyShot reduces the time it takes to create that perfect shot. From scientifically accurate material and environment presets to advanced material editing and animation, creating product visuals or sales and marketing imagery has never been easier.

Hardware Recommendations

Processor

This application is designed to take advantage of many CPU cores and scales well with the hardware according to benchmarks.

Graphics

Keyshot relies solely on the CPU for rendering, therefore the GPU does not make a difference specifically for this application. However Keyshot is typically used in conjunction with software that benefits from Quadro graphics cards, therefore we recommend viewing the graphic card requirements for those particular software packages.

Storage

We recommend a NVMe SSD for the operating system, applications and project files. 1TB is the most common capacity for Keyshot workstations. 1TB is fine if your projects are moderately sized. 2TB is recommended if your projects are large and you will you will use the workstation for a variety of professional applications.

If your projects are complex, are running multiple applications as the same time, and you want to maximize performance, we recommend two SSDs:

  1. Primary NVMe SSD: operating system and applications
  2. Secondary NVMe SSD: dedicated to active projects

For storage or backup, we recommend a SATA SSD or Hard Drive.

M.2 NVMe Gen4 SSD performs at ~5,000MB/s
2.5-inch SATA SSD performs at ~500MB/s
3.5-inch SATA Hard Drive performs at ~250MB/s

Memory

In general, 4GB of RAM per CPU core is recommended. For example, if you select a single 12-core processor, 32GB will suffice for basic tasks or 64GB for more demanding workloads.


Configuration Recommendations

HP Z8 G4 Workstation



  • Dual 28 cores, 2.2 GHz base frequency | Intel Xeon Gold 6238R
  • 192GB (12x 16GB) of 2933MT/s DDR4 ECC Memory
  • 1TB NVMe M.2 PCIe 3.0 Solid-State Drive

HP Z8 G4 Workstation



  • Dual 20 cores, 2.1 GHz base frequency | Intel Xeon Gold 5218R
  • 192GB (12x 16GB) of 2933MT/s DDR4 ECC Memory
  • 1TB NVMe M.2 PCIe 3.0 Solid-State Drive

HP Z840 Workstation



  • Dual 18-Core 2.3GHz Intel Xeon Haswell E5-2699 v3 [36-cores / 72-threads]
  • 128GB (8x 16GB) of 2133MT/s DDR4 ECC Memory
  • 500GB NVMe M.2 PCIe 3.0 Solid-State Drive
  • NVIDIA Quadro M2000 4GB

HP Z840 Workstation



  • Dual 10-Core 2.2GHz Intel Xeon Broadwell E5-2630 v4 [20-cores / 40-threads]
  • 64GB (8x 8GB) of 2400MT/s DDR4 ECC Memory
  • 500GB SATA 2.5" Solid-State Drive
  • NVIDIA Quadro M2000 4GB

HP Z6 G4 Workstation



  • 16 cores, 3.2 GHz base frequency | Intel Xeon W-3245
  • 96GB (6x 16GB) of 2933MT/s DDR4 ECC Memory
  • 500GB NVMe M.2 PCIe 3.0 Solid-State Drive

HP Z4 G4 Workstation



  • Intel Core i9-10900X (3.7 GHz base frequency, 10 cores)
  • 64GB (4x 16GB) of 2933MT/s DDR4 Memory
  • 500GB NVMe M.2 PCIe 3.0 Solid-State Drive

Condition

New: Purchased new from the manufacturer or authorized distribution. Package opened for customization process and testing. Ships in original retail manufacturer packaging.

Refurbished: Pulled from corporate environment in working condition. Tested upon arrival at our location and also after customization. Cosmetically grade A or B. Overall in good condition, but could have light scratches / scuffs. Ships in double-wall brown box with durable packaging material.
